Printable Wall Plate Template For The Sanus Fsf207 Wall plate top view swivel 3 d side view extension tilt fully assembled mount front view tilt side view retracted wall is on right wall is on right wall is on top wall is on top 15 75in 400mm max 23 62in 600mm max 7 87in 200mm min tv

Position the wall plate template 17 on the wall at your desired height Level the wall plate template and mark the hole locations Drill three pilot holes using a 3 8 in 10 mm diameter masonry drill bit IMPORTANT Pilot holes must be drilled to a depth of 3 in 75 mm Never drill into the mortar between blocks 1 Position the wall plate template 14 on the wall at your desired height Level the wall plate template and mark the hole locations NOTE For assistance in determining wall plate location see Height Finder at sanus 2 Drill two pilot holes using a 10 mm 3 8 in diameter drill bit IMPORTANT Pilot holes must be drilled to a depth of
